Controller, EcoStruxure Security Expert, web enabled security purpose controller
SKU :
SP-C-WEB
Loading...
No sellers found for this product.
AEDÂ 4,751.12
Excl. Tax
Free Shipping
To View the best prices please Sign in / Register.
Shipping:
Out of stock
- 1. EcoStruxure Security Expert, web enabled security purpose controller
- 2. Firmware update available
- 3. Black in color
- 4. Air-conditioning and lightining applications
- 5. DIN rail mounting
Controller, EcoStruxure Security Expert, web enabled security purpose controller
AEDÂ 4,751.12
- Description
- Specifications
- Environmental Data
- Documents
- Reviews
Description
Overview
| Activity | DBPRD |
|---|---|
| Device application | CONTROLREMOTE MONITORING |
| Product or component type | CONTROLLER |
| Function available | FIRMWARE UPDATE |
| Colour | BLACK |
| Directives | 2014/35/EU - LOW VOLTAGE DIRECTIVE2014/30/EU - ELECTROMAGNETIC COMPATIBILITY |
| [In] rated current | 120 MA |
| Width | 90 MM |
| Product certifications | CEACMARCM |
| Ambient air temperature for storage | -10…85 °C |
| Ambient air temperature for operation | 0…50 °C |
| Relative humidity | 0…93 % NON-CONDENSING |
| [Us] rated supply voltage | 11...14 V DC |
| Number of inputs | 18 DISCRETE |
| Number of outputs | 2 FORM C RELAY OUTPUT4 OPEN COLLECTOR NPN OUTPUT2 AUXILIARY OUTPUT1 ALARM OUTPUT |
| Height | 60 MM |
| Product weight | 376 G |
| Output voltage | 9 V DC |
| Output current | 0.7 A AUXILIARY OUTPUT1.1 A ALARM (CONTINUOUS)1500 MA ALARM (INRUSH) |
| Number of port | 2 RS485/WIEGAND |
| Range | ECOSTRUXURE SECURITY EXPERT |
| Product brand | SCHNEIDER ELECTRIC |
| Discrete input type | HIGH SECURITY MONITORED INPUTREADER INPUT |
| Mounting support | DIN RAIL |
| Number of alarms | 32 ALARM AREAS |
| Maximum output current | 1.1 A, AUXILIARY OUTPUT1.6 A, ALARM OUTPUT |
| Local signalling | 1 GREEN LED, POWER1 GREEN LED, STATUS1 RED LED, FAULT1 GREEN LED, ETHERNET CONNECTION1 GREEN LED, MODEM2 RED LED, READER DATA1 GREEN LED, BUZZER2 RED LED, RELAY ON8 GREEN/RED LED, INPUT STATUS |
| Standards | EN 50131-1:2006EN 50131-3:2009EN 50131-6:2008ICES-003: CLASS AUL 294UL 1610CAN/ULC-S304-06CAN/ULC-S559-04FCC CFR 47 PART 15: CLASS ACAN/ULC-S319-05 |
| Load type | INDUCTIVE LOAD FOR RELAY OUTPUTRESISTIVE LOAD FOR RELAY OUTPUT |
| Encryption protocol | AES (ADVANCED ENCRYPTION STANDARD) CONFORMING TO NIST |
| Integrated connection type | RS485MODEMETHERNET |
| Communication port protocol | UDP/IP 10/100 MBIT/S |
| Supply | POWER SUPPLY, |
| Length | 156 MM |
| Environmental characteristic | INDOOR USE |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 18.4 CM |
| Package 1 Width | 11 CM |
| Package 1 Length | 6.6 CM |
| Package 1 Weight | 400 G |
| Warranty (in months) | 18 |
Environmental data
Schneider Electric aims to achieve Net Zero status by 2050 through supply chain partnerships, lower impact materials, and circularity via our ongoing "Use Better, Use Longer, Use Again" campaign to extend product lifetimes and recyclability.
| Sustainability | Green PremiumTM label is Schneider Electric’s commitment to delivering products with best-in-class environmental performance. Green Premium promises compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products. Guide to assessing product sustainability is a white paper that clarifies global eco-label standards and how to interpret environmental declarations. |
|---|---|
| Sustainable packaging | ✓ |
| Take-back | No |
| Mercury free | ✓ |
| RoHS exemption information | Yes (Download) |
| REACh Regulation | REACh Declaration (Download) |
| EU RoHS Directive | EU RoHS Declaration (Download) |
| SCIP Number | D4580c73-85fd-491d-b2b2-7d8d1f1a1590 |
| WEEE Label | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
