Motor circuit breaker, TeSys GV3, 3P, 30-40 A, thermal magnetic, EverLink terminals

GV3P40
Be the first one to review this.
login_green To View the best prices please Sign in / Register.
Only 0 left in stock.
plain-icon

Description

TeSys GV motor circuit breaker, 3 poles (3P), 40A/690V, for 3-phase motor applications 18.5kW@400V. It provides a thermal-magnetic protection with a thermal setting range 30-40A, magnetic tripping at 14xIn, high breaking capacity Icu 50kA@400V. Connection by Everlink BTR screw terminals. Start-stop control by rotary knob guaranteed for 50 000 cycles AC-3. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).



Product Details

Activity PPCTR
Pincode Group default
Part Number GV3P40
Weight 983.0 g
Package1 Length*Width*Height 14.6 cm x 6.5 cm x 16.0 cm
Country of Manufacturing France
Rated current 40 A
[Ith] conventional free air thermal current 40 A conforming to IEC 60947-4-1
[ue] Rated Operational Voltage 690 V AC 50/60 Hz conforming to IEC 60947-2
[Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2
ambient air temperature for operation -20-60 °C
ambient air temperature for storage -40-80 °C
breaking capacity 100 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2, 50 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2, 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2, 12 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2, 6 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2
climatic withstand conforming to IACS E10
colour dark grey
compatibility code GV3P
control type rotary handle
depth 136 mm
device application motor protection
device short name GV3P
direct connector without
electrical durability 50000 cycles for AC-3 at 415 V In
fire resistance 960 °C conforming to IEC 60695-2-11
fixing mode 35 mm symmetrical DIN rail: clipped, panel: screwed (with 3 x M4 screws)
height 132 mm
IK degree of protection IK09 enclosure
IP degree of protection IP20 conforming to IEC 60529
magnetic tripping current 560-560 A
maximum operating rate 25 cyc/h
mechanical durability 50000 cycles
mechanical robustness shocks: 15 Gn for 11 ms closed conforming to IEC 60068-2-27, shocks: 30 Gn for 11 ms opened conforming to IEC 60068-2-27, vibrations: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6
motor power kW 18.5-18.5 kW at 400/415 V AC 50/60 Hz, 22-22 kW at 500 V AC 50/60 Hz, 37-37 kW at 690 V AC 50/60 Hz
net weight 0.96 kg
network frequency 50/60 Hz conforming to IEC 60947-4-1
network type AC
operating altitude 3000 m
operating position any position
phase failure sensitivity yes conforming to IEC 60947-4-1
Poles Description 3P
power dissipation per pole 8 W
product certifications CCC, UL, CSA, EAC, ATEX, LROS (Lloyds register of shipping), BV, ABS, DNV-GL, UKCA
product or component type motor circuit breaker
range TeSys Deca
range of product TeSys GV3
rated duty continuous conforming to IEC 60947-4-1
rated operational voltage limits 690 V AC 50/60 Hz conforming to IEC 60947-2
standards EN/IEC 60947-2, EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1
suitability for isolation yes conforming to IEC 60947-1
thermal protection adjustment range 30-40 A conforming to IEC 60947-4-1
tightening torque 5 N.m - on screw clamp terminal
trip unit rating 30-40 A
trip unit technology thermal-magnetic
utilisation category AC-3 conforming to IEC 60947-4-1
width 55 mm
[Ics] rated service short-circuit breaking capacity 100 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2, 100 % at 400/415 V AC 50/60 Hz conforming to IEC 60947-2, 100 % at 440 V AC 50/60 Hz conforming to IEC 60947-2, 50 % at 500 V AC 50/60 Hz conforming to IEC 60947-2, 50 % at 690 V AC 50/60 Hz conforming to IEC 60947-2
ambient air temperature for operation -20-60 °C
standards EN/IEC 60947-2, EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1
mechanical robustness shocks: 15 Gn for 11 ms contactor open, shocks: 30 Gn for 11 ms contactor closed, vibrations: 4 Gn, 5...300 Hz
Electrical Durability 50000 cycles for AC-3 at 415 V In
