APC Smart-UPS C 1500VA LCD 230V
SMC1500I
Product Details
| Activity | SPBPP |
|---|---|
| Pincode Group | default |
| Part Number | SMC1500I |
| Acoustic Level | 45 dBA |
| Additional Specification | entry level |
| Alarm | alarm when on battery : distinctive low battery alarm : configurable delays |
| ambient air temperature for storage | -15-45 °C |
| Battery Charger Power | 73 W rated |
| Battery Curve | C |
| Battery Life | 3-5 year(s) |
| Battery Power in Vah | 220 VAh runtime |
| Battery Recharge Time | 3 h |
| Battery Type | lead-acid battery |
| colour | black |
| Control Panel | multifunction LCD status and control console |
| Curve Equation | efficiency |
| Curve Fixed Loss | 0.011 |
| Curve Load Maximum | 100% |
| Curve Load Minimum | 2% |
| Curve Proportional Loss | 0 |
| Curve Square Loss | 0.0042 |
| Curve Test Cond Id | Curve fit of data measured in accordance with the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 230V/50Hz electrical input and balanced resistive load (PF = |
| depth | 43.9 cm |
| Extended Runtime | 0 |
| Free Slots | 0 |
| Graph Display | 1 |
| Harmonic Distortion | less than 5 % at full load |
| heat dissipation | 135 Btu/h |
| height | 21.9 cm |
| input voltage | 220 V, 240 V |
| input voltage limits | 170...300 V adjustable, 180...287 V |
| Liquid Value | 0 |
| Maximum Configurable Power in Va | 1500 VA |
| Maximum Configurable Power in w | 900 W |
| Mounting Location | front |
| mounting mode | not rack-mountable |
| Mounting Preference | no preference |
| net weight | 24.09 kg |
| network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
| Noise Suppression | full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Number of Battery Filled Slots | 0 |
| Number of Battery Free Slots | 0 |
| Number of Battery Replacement Quantity | 1 |
| Number of Power Module Filled Slots | 0 |
| Number of Power Module Free Slots | 0 |
| Number of Tare Power | 45 W |
| operating altitude | 0...10000 ft |
| Output Frequency | 47...53 Hz for 50 Hz nominal sync to mains , 57...63 Hz for 60 Hz nominal sync to mains |
| output voltage | 230 V |
| Performance Multiplier | 1 |
| product certifications | C-Tick, CE, CSA, GOST, VDE, EAC |
| Provided Equipment | CD with software, documentation CD, USB cable |
| Rated Power in Va | 1500 VA |
| rated power in W | 900 W |
| Redundant | No |
| relative humidity | 0-95 % |
| Show Note Op Temperature | No |
| Size Ups Version | internetworking, server, telecom |
| Storage Altitude | 0-50000 ft |
| Storage Relative Humidity | 0-95 % |
| Surge Energy Rate | 459 J |
| Two Post Mountable | 0 |
| Ups Size | S |
| Ups Type | line interactive |
| Usb Compatible | Yes |
| Value Multiplier | 5 |
| Wave Type | sine wave |
| width | 17.1 cm |
| Curve X-axis Maximum | 100% |
| Curve X-axis Minimum | 0% |
| Curve X-axis Title | load |
| Curve X-axis Units | percentage |
| Curve Y-axis Maximum | 100% |
| Curve Y-axis Minimum | 50% |
| Curve Y-axis Title | efficiency |
| Curve Y-axis Units | percentage |
| Main Input Voltage | 230 V |
| Input Connection Type | IEC 320 C14 |
| Output connection type | 8 IEC 320 C13 , 2 IEC Jumpers |
| ambient air temperature for operation | 0-40 °C |
| standards | EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018 |
