Name: Variable Speed Drive Atv12 - 0.37Kw - 0.55Hp - 100..120V - 1Ph - On Base Plate
Brand: Schneider Electric
SKU: ATV12P037F1
Price: 1952.4767 AED
Availability: InStock

Variable Speed Drive Atv12 - 0.37Kw - 0.55Hp - 100..120V - 1Ph - On Base Plate

Be the first one to review this.

SKU :

ATV12P037F1

Excl. Tax

To View the best prices please Sign in / Register.

ATV12, 100-120V, 1PH, 0.3

Range of product	ALTIVAR 12
Product or component type	VARIABLE SPEED DRIVE
Product specific application	SIMPLE MACHINE
Mounting mode	CABINET MOUNT
Communication port protocol	MODBUS
Supply frequency	50/60 HZ +/- 5 %
[Us] rated supply voltage	100...120 V - 15...10 %
nominal output current	2.4 A
Motor power kW	0.37 KW
Motor power hp	0.55 HP
EMC filter	WITHOUT EMC FILTER
IP degree of protection	IP20
Motor power hp	0.55 HP
Discrete input number	4
Discrete output number	2
Analogue input number	1
Analogue output number	1
Relay output number	1
Physical interface	2-WIRE RS 485
Connector type	1 RJ45
Continuous output current	2.4 A AT 4 KHZ
Method of access	SERVER MODBUS SERIAL
Speed drive output frequency	0.5…400 HZ
Speed range	1…20
Sampling duration	20 MS, TOLERANCE +/- 1 MS FOR LOGIC INPUT10 MS FOR ANALOGUE INPUT
Linearity error	+/- 0.3 % OF MAXIMUM VALUE FOR ANALOGUE INPUT
Frequency resolution	ANALOG INPUT: CONVERTER A/D, 10 BITSDISPLAY UNIT: 0.1 HZ
Time constant	20 MS +/- 1 MS FOR REFERENCE CHANGE
Transmission rate	9.6 KBIT/S19.2 KBIT/S38.4 KBIT/S
Transmission frame	RTU
Number of addresses	1…247
Data format	8 BITS, CONFIGURABLE ODD, EVEN OR NO PARITY
Communication service	READ HOLDING REGISTERS (03) 29 WORDSWRITE SINGLE REGISTER (06) 29 WORDSWRITE MULTIPLE REGISTERS (16) 27 WORDSREAD/WRITE MULTIPLE REGISTERS (23) 4/4 WORDSREAD DEVICE IDENTIFICATION (43)
Type of polarization	NO IMPEDANCE
4 quadrant operation possible	FALSE
Asynchronous motor control profile	QUADRATIC VOLTAGE/FREQUENCY RATIOVOLTAGE/FREQUENCY RATIO (V/F)SENSORLESS FLUX VECTOR CONTROL
Maximum output frequency	4 KHZ
Transient overtorque	150…170 % OF NOMINAL MOTOR TORQUE DEPENDING ON DRIVE RATING AND TYPE OF MOTOR
Acceleration and deceleration ramps	SLINEAR FROM 0 TO 999.9 SU
Motor slip compensation	ADJUSTABLEPRESET IN FACTORY
Switching frequency	2...16 KHZ ADJUSTABLE4...16 KHZ WITH DERATING FACTOR
Nominal switching frequency	4 KHZ
Braking to standstill	BY DC INJECTION
Brake chopper integrated	FALSE
Line current	11.4 A AT 100 V (HEAVY DUTY)9.3 A AT 120 V (HEAVY DUTY)
Maximum input current	9.3 A
Maximum output voltage	240 V
Apparent power	1.1 KVA AT 240 V (HEAVY DUTY)
Maximum transient current	3.6 A DURING 60 S (HEAVY DUTY)4.0 A DURING 2 S (HEAVY DUTY)
Network frequency	50...60 HZ
Relative symmetric network frequency tolerance	5 %
Prospective line Isc	1 KA
Base load current at high overload	2.4 A
Power dissipation in W	NATURAL: 29.0 W
With safety function Safely Limited Speed (SLS)	FALSE
With safety function Safe brake management (SBC/SBT)	FALSE
With safety function Safe Operating Stop (SOS)	FALSE
With safety function Safe Position (SP)	FALSE
With safety function Safe programmable logic	FALSE
With safety function Safe Speed Monitor (SSM)	FALSE
With safety function Safe Stop 1 (SS1)	FALSE
With sft fct Safe Stop 2 (SS2)	FALSE
With safety function Safe torque off (STO)	FALSE
With safety function Safely Limited Position (SLP)	FALSE
With safety function Safe Direction (SDI)	FALSE
Protection type	LINE SUPPLY OVERVOLTAGELINE SUPPLY UNDERVOLTAGEOVERCURRENT BETWEEN OUTPUT PHASES AND EARTHOVERHEATING PROTECTIONSHORT-CIRCUIT BETWEEN MOTOR PHASESAGAINST INPUT PHASE LOSS IN THREE-PHASETHERMAL MOTOR PROTECTION VIA THE DRIVE BY CONTINUOUS CALCULATION OF I²T
Tightening torque	0.8 N.M
Insulation	ELECTRICAL BETWEEN POWER AND CONTROL
Quantity per set	SET OF 1
Width	72 MM
Height	143 MM
Depth	102.2 MM
Net weight	0.7 KG
Operating altitude	> 1000...2000 M WITH CURRENT DERATING 1 % PER 100 M
Operating position	VERTICAL +/- 10 DEGREE
Product certifications	NOMCSAC-TickULGOSTRCMKC
Marking	CE
Standards	UL 508CUL 618000-5-1IEC 61800-5-1IEC 61800-3
Assembly style	ON BASE PLATE
Electromagnetic compatibility	ELECTRICAL FAST TRANSIENT/BURST IMMUNITY TEST LEVEL 4 CONFORMING TO IEC 61000-4-4ELECTROSTATIC DISCHARGE IMMUNITY TEST LEVEL 3 CONFORMING TO IEC 61000-4-2IMMUNITY TO CONDUCTED DISTURBANCES LEVEL 3 CONFORMING TO IEC 61000-4-6RADIATED RADIO-FREQUENCY ELECTROMAGNETIC FIELD IMMUNITY TEST LEVEL 3 CONFORMING TO IEC 61000-4-3SURGE IMMUNITY TEST LEVEL 3 CONFORMING TO IEC 61000-4-5VOLTAGE DIPS AND INTERRUPTIONS IMMUNITY TEST CONFORMING TO IEC 61000-4-11
Environmental class (during operation)	CLASS 3C3 ACCORDING TO IEC 60721-3-3CLASS 3S2 ACCORDING TO IEC 60721-3-3
Maximum acceleration under shock impact (during operation)	150 M/S² AT 11 MS
Maximum acceleration under vibrational stress (during operation)	10 M/S² AT 13...200 HZ
Maximum deflection under vibratory load (during operation)	1.5 MM AT 2...13 HZ
Overvoltage category	CLASS III
Regulation loop	ADJUSTABLE PID REGULATOR
Electromagnetic emission	RADIATED EMISSIONS ENVIRONMENT 1 CATEGORY C2 CONFORMING TO IEC 61800-3 2...16 KHZ SHIELDED MOTOR CABLECONDUCTED EMISSIONS WITH ADDITIONAL EMC FILTER ENVIRONMENT 1 CATEGORY C1 CONFORMING TO IEC 61800-3 4...12 KHZ SHIELDED MOTOR CABLE
Vibration resistance	1 GN (F = 13…200 HZ) CONFORMING TO IEC 60068-2-61.5 MM PEAK TO PEAK (F = 3…13 HZ) - DRIVE UNMOUNTED ON SYMMETRICAL DIN RAIL - CONFORMING TO IEC 60068-2-6
Shock resistance	15 GN CONFORMING TO IEC 60068-2-27 FOR 11 MS
Relative humidity	5…95 % WITHOUT CONDENSATION CONFORMING TO IEC 60068-2-35…95 % WITHOUT DRIPPING WATER CONFORMING TO IEC 60068-2-3
Noise level	0 DB
Pollution degree	2
Ambient air transport temperature	-25…70 °C
Ambient air temperature for operation	-10…40 °C WITHOUT DERATING40…60 °C WITH CURRENT DERATING 2.2 % PER °C
Ambient air temperature for storage	-25…70 °C
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	11.500 CM
Package 1 Width	18.500 CM
Package 1 Length	19.500 CM
Package 1 Weight	907.000 G
Unit Type of Package 2	S06
Number of Units in Package 2	45
Package 2 Height	75.000 CM
Package 2 Width	60.000 CM
Package 2 Length	80.000 CM
Package 2 Weight	54.400 KG
Warranty (in months)	18

Sustainability	Green PremiumTM label is Schneider Electric’s commitment to delivering products with best-in-class environmental performance. Green Premium promises compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products. Guide to assessing product sustainability is a white paper that clarifies global eco-label standards and how to interpret environmental declarations.
Sustainable packaging	✓
Take-back	No
Mercury free	✓
RoHS exemption information	Yes (Download)
REACh Regulation	REACh Declaration (Download)
EU RoHS Directive	EU RoHS Declaration (Download)
SCIP Number	488b1fd0-df04-41cb-85a8-34a5a8230847
EU RoHS Directive	Compliant By Exemption
WEEE Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Range of product	ALTIVAR 12
Product or component type	VARIABLE SPEED DRIVE
Product specific application	SIMPLE MACHINE
Mounting mode	CABINET MOUNT
Communication port protocol	MODBUS
Supply frequency	50/60 HZ +/- 5 %
[Us] rated supply voltage	100...120 V - 15...10 %
nominal output current	2.4 A
Motor power kW	0.37 KW
Motor power hp	0.55 HP
EMC filter	WITHOUT EMC FILTER
IP degree of protection	IP20
Motor power hp	0.55 HP
Discrete input number	4
Discrete output number	2
Analogue input number	1
Analogue output number	1
Relay output number	1
Physical interface	2-WIRE RS 485
Connector type	1 RJ45
Continuous output current	2.4 A AT 4 KHZ
Method of access	SERVER MODBUS SERIAL
Speed drive output frequency	0.5…400 HZ
Speed range	1…20
Sampling duration	20 MS, TOLERANCE +/- 1 MS FOR LOGIC INPUT10 MS FOR ANALOGUE INPUT
Linearity error	+/- 0.3 % OF MAXIMUM VALUE FOR ANALOGUE INPUT
Frequency resolution	ANALOG INPUT: CONVERTER A/D, 10 BITSDISPLAY UNIT: 0.1 HZ
Time constant	20 MS +/- 1 MS FOR REFERENCE CHANGE
Transmission rate	9.6 KBIT/S19.2 KBIT/S38.4 KBIT/S
Transmission frame	RTU
Number of addresses	1…247
Data format	8 BITS, CONFIGURABLE ODD, EVEN OR NO PARITY
Communication service	READ HOLDING REGISTERS (03) 29 WORDSWRITE SINGLE REGISTER (06) 29 WORDSWRITE MULTIPLE REGISTERS (16) 27 WORDSREAD/WRITE MULTIPLE REGISTERS (23) 4/4 WORDSREAD DEVICE IDENTIFICATION (43)
Type of polarization	NO IMPEDANCE
4 quadrant operation possible	FALSE
Asynchronous motor control profile	QUADRATIC VOLTAGE/FREQUENCY RATIOVOLTAGE/FREQUENCY RATIO (V/F)SENSORLESS FLUX VECTOR CONTROL
Maximum output frequency	4 KHZ
Transient overtorque	150…170 % OF NOMINAL MOTOR TORQUE DEPENDING ON DRIVE RATING AND TYPE OF MOTOR
Acceleration and deceleration ramps	SLINEAR FROM 0 TO 999.9 SU
Motor slip compensation	ADJUSTABLEPRESET IN FACTORY
Switching frequency	2...16 KHZ ADJUSTABLE4...16 KHZ WITH DERATING FACTOR
Nominal switching frequency	4 KHZ
Braking to standstill	BY DC INJECTION
Brake chopper integrated	FALSE
Line current	11.4 A AT 100 V (HEAVY DUTY)9.3 A AT 120 V (HEAVY DUTY)
Maximum input current	9.3 A
Maximum output voltage	240 V
Apparent power	1.1 KVA AT 240 V (HEAVY DUTY)
Maximum transient current	3.6 A DURING 60 S (HEAVY DUTY)4.0 A DURING 2 S (HEAVY DUTY)
Network frequency	50...60 HZ
Relative symmetric network frequency tolerance	5 %
Prospective line Isc	1 KA
Base load current at high overload	2.4 A
Power dissipation in W	NATURAL: 29.0 W
With safety function Safely Limited Speed (SLS)	FALSE
With safety function Safe brake management (SBC/SBT)	FALSE
With safety function Safe Operating Stop (SOS)	FALSE
With safety function Safe Position (SP)	FALSE
With safety function Safe programmable logic	FALSE
With safety function Safe Speed Monitor (SSM)	FALSE
With safety function Safe Stop 1 (SS1)	FALSE
With sft fct Safe Stop 2 (SS2)	FALSE
With safety function Safe torque off (STO)	FALSE
With safety function Safely Limited Position (SLP)	FALSE
With safety function Safe Direction (SDI)	FALSE
Protection type	LINE SUPPLY OVERVOLTAGELINE SUPPLY UNDERVOLTAGEOVERCURRENT BETWEEN OUTPUT PHASES AND EARTHOVERHEATING PROTECTIONSHORT-CIRCUIT BETWEEN MOTOR PHASESAGAINST INPUT PHASE LOSS IN THREE-PHASETHERMAL MOTOR PROTECTION VIA THE DRIVE BY CONTINUOUS CALCULATION OF I²T
Tightening torque	0.8 N.M
Insulation	ELECTRICAL BETWEEN POWER AND CONTROL
Quantity per set	SET OF 1
Width	72 MM
Height	143 MM
Depth	102.2 MM
Net weight	0.7 KG
Operating altitude	> 1000...2000 M WITH CURRENT DERATING 1 % PER 100 M
Operating position	VERTICAL +/- 10 DEGREE
Product certifications	NOMCSAC-TickULGOSTRCMKC
Marking	CE
Standards	UL 508CUL 618000-5-1IEC 61800-5-1IEC 61800-3
Assembly style	ON BASE PLATE
Electromagnetic compatibility	ELECTRICAL FAST TRANSIENT/BURST IMMUNITY TEST LEVEL 4 CONFORMING TO IEC 61000-4-4ELECTROSTATIC DISCHARGE IMMUNITY TEST LEVEL 3 CONFORMING TO IEC 61000-4-2IMMUNITY TO CONDUCTED DISTURBANCES LEVEL 3 CONFORMING TO IEC 61000-4-6RADIATED RADIO-FREQUENCY ELECTROMAGNETIC FIELD IMMUNITY TEST LEVEL 3 CONFORMING TO IEC 61000-4-3SURGE IMMUNITY TEST LEVEL 3 CONFORMING TO IEC 61000-4-5VOLTAGE DIPS AND INTERRUPTIONS IMMUNITY TEST CONFORMING TO IEC 61000-4-11
Environmental class (during operation)	CLASS 3C3 ACCORDING TO IEC 60721-3-3CLASS 3S2 ACCORDING TO IEC 60721-3-3
Maximum acceleration under shock impact (during operation)	150 M/S² AT 11 MS
Maximum acceleration under vibrational stress (during operation)	10 M/S² AT 13...200 HZ
Maximum deflection under vibratory load (during operation)	1.5 MM AT 2...13 HZ
Overvoltage category	CLASS III
Regulation loop	ADJUSTABLE PID REGULATOR
Electromagnetic emission	RADIATED EMISSIONS ENVIRONMENT 1 CATEGORY C2 CONFORMING TO IEC 61800-3 2...16 KHZ SHIELDED MOTOR CABLECONDUCTED EMISSIONS WITH ADDITIONAL EMC FILTER ENVIRONMENT 1 CATEGORY C1 CONFORMING TO IEC 61800-3 4...12 KHZ SHIELDED MOTOR CABLE
Vibration resistance	1 GN (F = 13…200 HZ) CONFORMING TO IEC 60068-2-61.5 MM PEAK TO PEAK (F = 3…13 HZ) - DRIVE UNMOUNTED ON SYMMETRICAL DIN RAIL - CONFORMING TO IEC 60068-2-6
Shock resistance	15 GN CONFORMING TO IEC 60068-2-27 FOR 11 MS
Relative humidity	5…95 % WITHOUT CONDENSATION CONFORMING TO IEC 60068-2-35…95 % WITHOUT DRIPPING WATER CONFORMING TO IEC 60068-2-3
Noise level	0 DB
Pollution degree	2
Ambient air transport temperature	-25…70 °C
Ambient air temperature for operation	-10…40 °C WITHOUT DERATING40…60 °C WITH CURRENT DERATING 2.2 % PER °C
Ambient air temperature for storage	-25…70 °C
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	11.500 CM
Package 1 Width	18.500 CM
Package 1 Length	19.500 CM
Package 1 Weight	907.000 G
Unit Type of Package 2	S06
Number of Units in Package 2	45
Package 2 Height	75.000 CM
Package 2 Width	60.000 CM
Package 2 Length	80.000 CM
Package 2 Weight	54.400 KG
Warranty (in months)	18

Sustainability	Green PremiumTM label is Schneider Electric’s commitment to delivering products with best-in-class environmental performance. Green Premium promises compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products. Guide to assessing product sustainability is a white paper that clarifies global eco-label standards and how to interpret environmental declarations.
Sustainable packaging	✓
Take-back	No
Mercury free	✓
RoHS exemption information	Yes (Download)
REACh Regulation	REACh Declaration (Download)
EU RoHS Directive	EU RoHS Declaration (Download)
SCIP Number	488b1fd0-df04-41cb-85a8-34a5a8230847
EU RoHS Directive	Compliant By Exemption
WEEE Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
