EasyPact TVS differential thermal overload relay 2.5...4 A - class 10A
- Description
- Specifications
- Documents
- Reviews
Description
Easy TeSys Protect
Easy TeSys Protect thermal overload relays Thermal overload relays compatible with EasyTeSys contactors up to 630A are designed to cover the range of motor ratings up to 630 A, which could be stand-alone or optional direct mounted under Easy TeSys Control contactor
Easy installation
Easy TeSys Protect components are easy to install in new panels or retrofit in existing motor control panels to perform the essential motor starter and switching functions.
Designed for Compatibility
It can be used as a stand-alone unit or optionally mounted directly under the Easy TeSys Control contactor. Reduces the amount of cabling and time required, while enhancing reliability.
Extended flexibility
A maximum number of solutions are covered with an extended range of products, helping you reduce stocking requirements and simplify design.
Enhance your power solutions with our extensive range of accessories
Contact blocks
Auxiliary Contact
Mounting accessories
Gain peace of mind, quality, and value for your installations
Comprehensive, simple, and capable
motor starter solution
Easy TeSys thermal overload relays are engineered to safeguard AC circuits and motors from various electrical faults, including overloads, phase failure, extended starting durations, and prolonged stalled rotor conditions.. Available worldwide, it is multi-standard certified and environmentally compliant.
Essential Protection
Lorem Ipsum is simply dummy text of the printing and
Reliable
Lorem Ipsum is simply dummy text of the printing and
Simplicity and Flexibility
Lorem Ipsum is simply dummy text of the printing and
Overview
| Activity | PPCTR |
|---|---|
| Part Number | LRE08 |
| Weight | 144.0 g |
| Package1 Length*Width*Height | 8.4 cm x 8.1 cm x 5.3 cm |
| Country of Manufacturing | China |
| [Ith] conventional free air thermal current | 5 A for signalling circuit |
| [ue] Rated Operational Voltage | <= 690 V AC |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-4-1 |
| [Uimp] rated impulse withstand voltage | 6 kV |
| ambient air temperature for operation | -20-60 °C without derating conforming to IEC 60947-4-1, -20-70 °C with derating |
| ambient air temperature for storage | -60-80 °C |
| associated fuse rating | 10 A gG for power circuit, 6 A aM for power circuit, 5 A gG for signalling circuit |
| auxiliary contact composition | 1 NO + 1 NC |
| colour | grey (RAL 7011) |
| connections - terminals | power circuit: screw clamp terminals 1 1.5-6 mm² - cable stiffness: flexible without cable end, power circuit: screw clamp terminals 1 1-4 mm² - cable stiffness: flexible with cable end, power circuit: screw clamp terminals 1 1-6 mm² - cable stiffness: solid without cable end, signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible without cable end, signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible with cable end, signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: solid without cable end |
| control type | push-button red stop: , push-button green reset: |
| Depth | 70 mm |
| device short name | LRE |
| dielectric strength | 6 kV at 50 Hz conforming to IEC 60255-5 |
| electromagnetic compatibility | surge withstand: 6 kV conforming to IEC 60801-5 |
| fire resistance | 850 °C conforming to IEC 60068-2-1 |
| Height | 44.5 mm |
| IP degree of protection | IP20 conforming to IEC 60529 |
| local signalling | trip indicator |
| mechanical robustness | shocks: 6 Gn for 11 ms conforming to IEC 60068-2-7, vibrations: 3 Gn conforming to IEC 60068-2-6 |
| mounting support | under contactor, plate, with specific accessories, rail, with specific accessories |
| net weight | 0.13 kg |
| network frequency | 50...60 Hz |
| network type | AC |
| phase failure sensitivity | tripping current 130 % of Ir on two phase, the last one at 0 conforming to IEC 60947-4-1 |
| product certifications | EAC |
| product compatibility | LC1E06...38 |
| product or component type | differential thermal overload relay |
| protective treatment | TH conforming to IEC 60068 |
| Range | EasyPact |
| rated operational voltage limits | <= 690 V AC |
| relay application | motor protection |
| signalling function | relay trip indicator |
| standards | IEC 60947-5-1, IEC 60947-4-1 |
| temperature compensation | -20-60 °C |
| thermal overload class | class 10A conforming to IEC 60947-4-1 |
| thermal protection adjustment range | 2.5-4 A |
| tightening torque | power circuit: 1.7 N.m - on screw clamp terminals, signalling circuit: 1.7 N.m - on screw clamp terminals |
| tripping threshold | 1.14 +/- 0.06 Ir conforming to IEC 60947-4-1 |
| width | 45 mm |
| electromagnetic compatibility | surge withstand: 6 kV conforming to IEC 60801-5 |
| ambient air temperature for operation | -20-60 °C without derating conforming to IEC 60947-4-1, -20-70 °C with derating |
| standards | IEC 60947-5-1, IEC 60947-4-1 |
| local signalling | trip indicator |
| product compatibility | LC1E06...38 |
| mechanical robustness | shocks: 6 Gn for 11 ms conforming to IEC 60068-2-7, vibrations: 3 GN conforming to IEC 60068-2-6 |
