TeSys K - differential thermal overload relays - 0.36...0.54 A - class 10A
Description
TeSys K Overload Relays
With its integrated manual-automatic reset and simple installation, TeSys K bimetallic overload relays are very reliable and cover the whole range of motor ratings up to 14A. They can be combined with TeSys K contactors to form an extremely compact starter.
Protection
Tesys K thermal overload relays are designed to protect a.c. circuits and motors against overloads. stalling, and phase loss
Compact size
The range delivers strong performance for its compact size and promises seamless integration in all applications.
Versatile
Commonly utilized across various sectors, including industry, infrastructure, and construction, this thermal overload relay is crafted for seamless control in simple applications.
Enhance your power solutions with our extensive range of accessories
Terminal Block
Auxiliary Contact Block
TeSys K Contactor
Gain peace of mind, quality, and value for your installations
Optimized for common applications
TeSys K thermal overload relays are designed to protect a.c. circuits and motors against overloads.
Simple to select and install at an optimized budget, the range delivers strong performance for its compact size and promises seamless integrations in all applications.
High performance
Lorem Ipsum is simply dummy text of the printing and
Compact Dimensions
Lorem Ipsum is simply dummy text of the printing and
Continuity of service
Lorem Ipsum is simply dummy text of the printing and
Product Details
| Weight (in Kg) | 0.156 |
|---|---|
| Net weight | 0.145 kg |
| Product Or Component Type | differential thermal overload relay |
| Control Type | red push-button: trip test function blue push-button: stop and manual reset selector switch: manual or automatic reset |
| Protective Treatment | TC conforming to IEC 60068 TC conforming to DIN 50016 |
| Network frequency | <= 400 Hz |
| Auxiliary Contact Composition | 1 NO + 1 NC |
| Thermal Protection Adjustment Range | 0.36-0.54 A |
| [IP] Degree of Protection | IP2x conforming to IEC 60529 |
| Connections Terminals | screw clamp terminals 1 cable(s) 1.5-4 mm²solid screw clamp terminals 2 cable(s) 1.5-4 mm²solid screw clamp terminals 1 cable(s) 0.75-4 mm²flexible without cable end screw clamp terminals 2 cable(s) 0.75-4 mm²flexible without cable end screw clamp terminals 1 cable(s) 0.34-2.5 mm²flexible with cable end screw clamp terminals 2 cable(s) 0.34-1.5 mm²flexible with cable end |
| [Uimp] Rated Impulse Wthstand Voltage | 6 kV |
| phase_failure_sensitivity | yes conforming to IEC 60947-4-1 |
| Ambient air temperature for operation | -20-55 °C without derating conforming to IEC 60947 -30-60 °C with derating conforming to IEC 60947 |
| Range of Product | TeSys K thermal overload relays |
| Tightening Torque | 1.3 N.m - on screw clamp terminals - with screwdriver Philips No 2 1.3 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm 1.3 N.m - on screw clamp terminals - with screwdriver pozidriv No 2 |
| Standards | IEC 60947 NF C 63-650 VDE 0660 BS 4941 |
| Product Certifications | UL CSA UKCA |
| Mechanical Robustness | shocks NO contact: 10 Gn for 11 ms conforming to IEC 60068-2-27 shocks NC contact: 10 Gn for 11 ms conforming to IEC 60068-2-27 vibrations NO contact: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 vibrations NC contact: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| [Ith] Conventional Free Air Thermal Current | 6 A for signalling circuit |
| [ui] Rated Insulation Voltage | power circuit: 690 V conforming to BS 4941 power circuit: 690 V conforming to IEC 60947 power circuit: 750 V conforming to VDE 0110 group C power circuit: 600 V conforming to CSA C22.2 No 14 |
| Associated Fuse Rating | 6 A gG for signalling circuit conforming to VDE 0660 6 A gG for signalling circuit conforming to IEC 60947 |
| Mounting support | under contactor plate, with specific accessories rail, with specific accessories |
| Fire Resistance | 850 °C conforming to IEC 60695-2-1 |
| Power Dissipation Per Pole | 2 W |
| Flame Retardance | V1 conforming to UL 94 requirement 2 conforming to NF F 16-101 requirement 2 conforming to NF F 16-102 |
| Product Compatibility | LP1K LC7K LP4K LC1K |
| Local Signalling | trip indicator (yellow) |
| Relay Application | motor protection |
| Thermal Overload Class | class 10A conforming to IEC 60947-4-1 |
| Device short name | LR2K |
| Depth | 65 mm |
| Ambient air temperature for storage | -40-70 °C |
| Height | 58 mm |
| width | 45 mm |
| Operating altitude | 2000 m without derating |
| Compatibility code | LR2K |
| Network type | AC DC |
| [Ue] Rated Operational Voltage | <= 690 V for power circuit 690 V AC AC-15 for signalling circuit 250 V DC DC-13 for signalling circuit |
| Brand | Schneider Electric |
| Height | 8.5 |
| Length | 4.8 |
| Width | 7.2 |
