EasyPact TVS contactor 3P(3 NO) - AC-3 - <= 440 V 300A - 220 V AC coil
Description
Easy TeSys Control Contactors
The Easy TeSys Control up to 630A for AC3 (335kW/400V) and 1000A for AC1 applications range provides you a perfect balance of the performances you need, with simplicity of selection, purchasing and stocking, and with an extended flexibility.
Direct Mounting
The complete range offers optional direct mounting under contactors, class 10A, Multi standard compliance.
Contactor Ratings
Contactor 3 Pole: Current Rating: 6A to 630A, AC3 Rating. Contactor 4 Pole: Current Rating: 16A to 125A, AC1 duty.
Compact Strength
One size from 0,37 to 15kW. Width = 44,5 mm. Icu breaking capacity up to 100kA.
Enhance your power solutions with our extensive range of accessories
Earth leakage protection
Direct rotary handle
Auxiliary contact
Gain peace of mind, quality, and value for your installations
LV motor starters made easy
Easy TeSys delivers the adjusted capabilities to meet most LV motor control needs. Its motor starter components deliver the optimal balance between performance and cost without compromising quality.
Easy TeSys is the exact fit, providing you:
- The performance you need
- For an optimised budget
- With the quality you demand
High Fault Protection
Lorem Ipsum is simply dummy text of the printing and
Modular Design
Lorem Ipsum is simply dummy text of the printing and
Enhanced Safety
Lorem Ipsum is simply dummy text of the printing and
Product Details
| Weight (in Kg) | 9.446 |
|---|---|
| Net weight | 8.5 kg |
| Pole Contact Composition | 3 NO |
| Product Or Component Type | contactor |
| Mechanical Durability | 5000000 cycles |
| Insulation Resistance | > 10 MOhm for control circuit |
| Minimum Switching Current | 5 mA for control circuit |
| Minimum Switching Voltage | 17 V for control circuit |
| Poles Description | 3P |
| Average Impedance | 0.3 mOhm - Ith 320 A 50 Hz for power circuit |
| Contactor Application | resistive load motor control |
| Permissible Ambient Air Temperature Around The Device | -20-70 °C at Uc |
| [IP] Degree of Protection | IP00 conforming to IEC 60529 |
| Connections Terminals | control circuit: screw clamp terminals 1 1-4 mm² - cable stiffness: flexible without cable end control circuit: screw clamp terminals 2 1-4 mm² - cable stiffness: flexible without cable end control circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible with cable end control circuit: screw clamp terminals 1 1-4 mm² - cable stiffness: solid without cable end control circuit: screw clamp terminals 2 1-4 mm² - cable stiffness: solid without cable end control circuit: screw clamp terminals 1 1-2.5 mm² - cable stiffness: flexible with cable end power circuit: cable with lug - external diameter: 240 mm power circuit: bars 2 - busbar cross section: 5 x 30 mm |
| [Uimp] Rated Impulse Wthstand Voltage | 8 kV coil not connected to the power circuit conforming to IEC 60947 |
| Irms Rated Making Capacity | 3000 A at 440 V AC for power circuit conforming to IEC 60947-4-1 |
| Ambient air temperature for operation | -5-55 °C |
| Tightening Torque | control circuit: 1.2 N.m power circuit: 35 N.m control circuit: 1.4 N.m power circuit: 37 N.m |
| Standards | IEC 60947-1 IEC 60947-4-1 IEC 60947-5-1 |
| Product Certifications | EAC CE |
| Mechanical Robustness | vibrations contactor open: 1.5 Gn, 5...300 Hz vibrations contactor closed: 3 Gn, 5...300 Hz shocks contactor open: 6 Gn for 11 ms shocks contactor closed: 7 Gn for 11 ms |
| [Ith] Conventional Free Air Thermal Current | 320 A (at 40 °C) |
| [ui] Rated Insulation Voltage | 690 V conforming to IEC 60947-4-1 |
| Associated Fuse Rating | 10 A gG at <= 690 V coordination type 1 for control circuit conforming to IEC 60947-5-1 500 A gG at <= 690 V coordination type 1 for power circuit |
| Mounting support | plate |
| Control Circuit Type | AC at 50 Hz |
| Control Circuit Voltage Limits | operational: 0.85...1.1 Uc at 50 Hz (at <55 °C) drop-out: 0.35...0.55 Uc at 50 Hz (at <55 °C) |
| Electrical Durability | 400000 cycles AC-1 500000 cycles AC-3 |
| Fire Resistance | 850 °C conforming to IEC 60695-2-1 |
| Heat Dissipation | 8-8 W for control circuit |
| Hold-In Power Consumption In VA | 10-10 VA 50 Hz cos phi 0.9 (at 20 °C) 10-10 VA 60 Hz cos phi 0.9 (at 20 °C) |
| Inrush Power In VA | 650-650 VA 50 Hz cos phi 0.9 (at 20 °C) 650-650 VA 60 Hz cos phi 0.9 (at 20 °C) |
| Maximum Operating Rate | 1200 cyc/h 55 °C |
| Motor Power Kw | 90 kW at 220...230 V AC 50/60 Hz (AC-3) 160 kW at 380...400 V AC 50/60 Hz (AC-3) 160 kW at 415 V AC 50/60 Hz (AC-3) 185 kW at 440 V AC 50/60 Hz (AC-3) 200 kW at 500 V AC 50/60 Hz (AC-3) 250 kW at 660...690 V AC 50/60 Hz (AC-3) |
| Operating Time | 40...65 ms on closing 100...170 ms on opening |
| Power Dissipation Per Pole | 27 W AC-3 31 W AC-1 |
| Rated Breaking Capacity | 2400 A at 440 V for power circuit conforming to IEC 60947 |
| [Icw] rated short-time withstand current | 2200 A 40 °C - 10 s for power circuit |
| Device short name | LC1E |
| Depth | 219 mm |
| Ambient air temperature for storage | -60-80 °C |
| Height | 206 mm |
| Overvoltage Category | III |
| width | 213 mm |
| Pollution degree | 3 |
| Utilisation category | AC-1 AC-3 |
| Operating altitude | 3000 m without derating |
| Non-Overlap Time | 1.5 ms on energisation guaranteed between NC and NO contact 1.5 ms on de-energisation guaranteed between NC and NO contact |
| [Uc] Control Circuit Voltage | 220 V AC 50 Hz |
| [Ue] Rated Operational Voltage | power circuit: <= 690 V AC 50/60 Hz |
| Brand | Schneider Electric |
| Height | 25 |
| Length | 32 |
| Width | 25.5 |
