Schneider Electric Circuit breaker, ComPacT NSX100N, 50kA/415VAC, 3 poles, TMD trip unit 32A, 50 degrees C

C10N3TM032C
Be the first one to review this.

Excl. Tax

login_green To View the best prices please Sign in / Register.
loader
Loading...

Description

Schneider Electric Circuit breaker, ComPacT NSX100N, 50kA/415VAC, 3 poles, TMD trip unit 32A, 50 degrees C

Product Details

Activity code PPCCB
Breaking Capacity Code N 50 kA 415 V AC , N 50 kA 415 V AC , N 50 kA 415 V AC , N 50 kA 415 V AC
Device Application distribution
Device Short Name NSX100N
Height 0
Mounting Mode fixed
Network Frequency 50/60 Hz
Network Type AC
Product or Component Type circuit breaker
Width 0
Protected poles description 3D
Trip unit name TM-D
Trip unit protection functions LI
Trip unit technology thermal-magnetic
[Ue] rated operational voltage 690 V AC 50/60 Hz , 690 V AC 50/60 Hz , 690 V AC 50/60 Hz
[In] rated current 32 A at 50 °C , 32 A at 50 °C
Breaking capacity 90 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 , 90 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 , 90 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 , 90 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 , 90 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 , 90 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 , 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 , 36 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 , 36 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 , 36 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 , 36 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 , 36 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 , 36 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 , 35 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 , 35 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 , 35 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 , 35 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 , 35 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 , 35 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 , 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 , 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 , 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 , 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 , 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 , 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2
Suitability for isolation yes conforming to EN/IEC 60947-2 , yes conforming to EN/IEC 60947-2
Utilisation category category A
Range ComPacT new generation
Control Type toggle
Length 0
Poles description 3P
