Contactor,EasyPact TVS,3P(3NO),AC-3,=440V,160A,220V AC coil,60Hz
- Description
- Specifications
- Reviews
Description
Easy TeSys Control Contactors
The Easy TeSys Control up to 630A for AC3 (335kW/400V) and 1000A for AC1 applications range provides you a perfect balance of the performances you need, with simplicity of selection, purchasing and stocking, and with an extended flexibility.
Direct Mounting
The complete range offers optional direct mounting under contactors, class 10A, Multi standard compliance.
Contactor Ratings
Contactor 3 Pole: Current Rating: 6A to 630A, AC3 Rating. Contactor 4 Pole: Current Rating: 16A to 125A, AC1 duty.
Compact Strength
One size from 0,37 to 15kW. Width = 44,5 mm. Icu breaking capacity up to 100kA.
Enhance your power solutions with our extensive range of accessories
Earth leakage protection
Direct rotary handle
Auxiliary contact
Gain peace of mind, quality, and value for your installations
LV motor starters made easy
Easy TeSys delivers the adjusted capabilities to meet most LV motor control needs. Its motor starter components deliver the optimal balance between performance and cost without compromising quality.
Easy TeSys is the exact fit, providing you:
- The performance you need
- For an optimised budget
- With the quality you demand
High Fault Protection
Lorem Ipsum is simply dummy text of the printing and
Modular Design
Lorem Ipsum is simply dummy text of the printing and
Enhanced Safety
Lorem Ipsum is simply dummy text of the printing and
Overview
| Activity | PPCTR |
|---|---|
| Weight (in Kg) | 0.026 kg |
| [ith] Conventional Free Air Thermal Current | 200 A (at 40 °C) |
| Pole Contact Composition | 3 NO |
| [ue] Rated Operational Voltage | power circuit: <= 690 V AC 50/60 Hz |
| Product or Component Type | contactor |
| [uc] Control Circuit Voltage | 220 V AC 60 Hz |
| Range | EasyPact |
| Control Circuit Type | AC at 60 Hz |
| Control Circuit Voltage Limits | 0.85...1.1 Uc (55-55 °C):operational 60 Hz, 0.35...0.55 Uc (55-55 °C):drop-out 60 Hz |
| Fire Resistance | 850 °C conforming to IEC 60695-2-1 |
| Maximum Operating Rate | 1200 cyc/h 55 °C |
| Operating Time | 20...50 ms on closing, 6...20 ms on opening |
| Poles Description | 3P |
| Operating Altitude | 3000 m without derating |
| Net Weight | 2.3 kg |
| Mechanical Durability | 400000 cycles |
| Standards | IEC 60947-1, IEC 60947-5-1, IEC 60947-4-1 |
| Power Dissipation per Pole | 24 W AC-1, 15 W AC-3 |
| Utilisation Category | AC-1#|#AC-3 |
| [icw] Rated Short-Time withstand Current | 1400 A 40 °C - 10 s for power circuit |
| [uimp] Rated Impulse withstand Voltage | 8 kV coil not connected to the power circuit conforming to IEC 60947 |
| [ie] Rated Operational Current | 160 A (at <55 °C) at <= 440 V AC AC-3 for power circuit, 200 A (at <55 °C) at <= 440 V AC AC-1 for power circuit |
| Product Certifications | EAC#|#CE |
| [ui] Rated Insulation Voltage | 690 V conforming to IEC 60947-4-1 |
| Height | 158 mm |
| Depth | 132 mm |
| Width | 120 mm |
| Range | EasyPact |
