range of product |
ISW 40...125
|
|
---|---|---|
range |
Acti 9
|
|
product or component type |
Isolator
|
|
device application |
Isolation
|
[Ie] rated operational current |
63 A at 415 V AC
|
|
---|---|---|
[Ui] rated insulation voltage |
6 kV
|
|
[Uimp] rated impulse withstand voltage |
500 V
|
|
poles description |
3P
|
|
rated breaking capacity |
2.5 kA
|
|
short-circuit withstand |
20 A
|
|
[Us] rated supply voltage |
48 V DC 1P
100 V DC 2P |
|
utilisation category |
AC-22
|
|
total number of 18 mm modules |
3
|
|
product destination |
Distribution board
|
ambient air temperature for operation |
-20…50 °C
|
|
---|---|---|
pollution degree |
3
|
|
standards |
IEC 60947-3
IEC 60669-1 |
Product Name | Acti 9 Isolator xSW 3P 63A |
---|---|
Range Name | Acti 9 |
Tax Class | GST-18 |
