Schneider Electric EasyPact TVS thermal overload relay 0.4...0.63 A - class 10A

LRE04
Be the first one to review this.
login_green To View the best prices please Sign in / Register.
Only 0 left in stock.
plain-icon

Description

The LRE relay is a differential thermal overload relays for use with fuses or magnetic circuit-breakers GV2 L and GV3 L. Its thermal setting range is 0.4-0.63A 50/60Hz and the tripping class is 10A conforming to IEC 60947-4-1. It can be direct mounted on EasyPact TVS contactors with screw clamp terminals connection. It protects unbalanced loads and motors with 0.12 - 0.18kW at 400VAC. It provides manual or automatic reset, trip auxiliary contact and flag indicator. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC, EAC, Marine) and Green Premium compliant (RoHs/Reach).

Product Details

Weight (in Kg) 0.15
Net weight 0.13 kg
Product or Component Type differential thermal overload relay
Colour grey (RAL 7011)
Control Type push-button red stop:
push-button green reset:
Protective Treatment TH conforming to IEC 60068
[ue] Rated Operational Voltage <= 690 V AC
Phase Failure Sensitivity tripping current 130 % of Ir on two phase, the last one at 0 conforming to IEC 60947-4-1
Tripping Threshold 1.14 +/- 0.06 Ir conforming to IEC 60947-4-1
Network frequency 50...60 Hz
Auxiliary Contact Composition 1 NO + 1 NC
Temperature Compensation -20-60 °C
Thermal Protection Adjustment Range 0.4-0.63 A
Connections Terminals power circuit: screw clamp terminals 1 1.5-6 mm² - cable stiffness: flexible without cable end
power circuit: screw clamp terminals 1 1-4 mm² - cable stiffness: flexible with cable end
power circuit: screw clamp terminals 1 1-6 mm² - cable stiffness: solid without cable end
signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible without cable end
signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible with cable end
signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: solid without cable end
Standards IEC 60947-4-1
IEC 60947-5-1
Mechanical Robustness shocks: 6 Gn for 11 ms conforming to IEC 60068-2-7
vibrations: 3 Gn conforming to IEC 60068-2-6
Tightening Torque power circuit: 1.7 N.m - on screw clamp terminals
signalling circuit: 1.7 N.m - on screw clamp terminals
Associated Fuse Rating 2 A gG for power circuit
1 A aM for power circuit
5 A gG for signalling circuit
Mounting support under contactor
plate, with specific accessories
rail, with specific accessories
Range EasyPact
[ui] Rated Insulation Voltage 690 V conforming to IEC 60947-4-1
[Uimp] rated impulse withstand voltage 6 kV
Ambient air temperature for storage -60-80 °C
Depth 70 mm
Device short name LRE
[Ith] Conventional Free Air Thermal Current 5 A for signalling circuit
Electromagnetic Compatibility surge withstand: 6 kV conforming to IEC 60801-5
Height 44.5 mm
IP degree of protection IP20 conforming to IEC 60529
Dielectric Strength 6 kV at 50 Hz conforming to IEC 60255-5
Local Signalling trip indicator
width 45 mm
Product Compatibility LC1E06...38
Signalling Function relay trip indicator
Fire Resistance 850 °C conforming to IEC 60068-2-1
Network type AC
Relay Application motor protection
Thermal Overload Class class 10A conforming to IEC 60947-4-1
Brand Schneider Electric
